100x100mm Half Mirror Coaxial Light White

Product Details Unique Design Prevents Ghost Images Available in Red, White, and Blue Ideal for Use with High Resolution Cameras CCS High-Resolution Coaxial Lights are designed to provide diffused lighting for high-resolution imaging of shiny, flat surfaces. Designed to prevent ghost reflections and achieve higher system resolution, these coaxial lights integrate a unique thin beamsplitter to minimize deviation through in the imaging path. CCS High-Resolution Coaxial Lights are ideal for industrial imaging applications including inspection of glossy surfaces, pattern detection on PCBs, and measuring dimensions of glass. Specifications General Model Number: LFV3-G-100SW Type of Illumination: LED Illuminator Manufacturer: CCS Geometry: Coaxial Light Illumination Mode: Constant Physical & Mechanical Properties Dimensions (mm): W 110 mm x D 183 mm x H 105 mm Weight (g): 990 Active Area (mm): 100 mm x 102 mm Optical Properties Color: White Electrical Power Consumption (W): 34 Hardware & Interface Connectivity Input Voltage (V): 24 Power Supply: Power Supply Required and Sold Separately: USA: #73-491 Europe: #73-491 Japan: #89-513 Korea: #33-773 China: #73-491 Environmental & Durability Factors Color Temperature (K): 7000 Regulatory Compliance RoHS 2015: Exempt × Reach 224: Contains SVHC(s) × Certificate of Conformance: View ×
