103mm, 355nm JENar Silverline F-Theta Scanning Lens

Product Details Low-Absorption Fused Silica Substrates for High-Power Laser Applications Large Scan Fields Up to 328mm x 328mm High Damage Thresholds and Low Telecentricity Errors Jenoptik JENar F-Theta Scanning Lenses Also Available Jenoptik JENar Silverline F-Theta Scanning Lenses provide flat field at the image plane and feature low-absorption fused silica substrates, making them suitable for high-power laser applications. These F-Theta lenses offer high damage thresholds to handle beam powers of up to four kilowatts without active cooling and are available in various wavelengths ranging from 266nm to 1100nm. With large processing areas up to 328mm x 328mm, low telecentricity errors, and diffraction-limited image quality, these lenses allow for high spot consistency and increased throughput over the entire scanning range. With their patented stackable mounting technology, these lenses compensate for thermal stresses and improve the stability of the optical components, ensuring high-precision adjustment and position control in OEM systems. Jenoptik JENar Silverline F-Theta Scanning Lenses were specially developed for applications requiring high-power and short-pulse Nd:YAG, Yb:doped, and fiber laser sources and are used in conjunction with galvanometers and beam expanders . Contact us if your application requires Jenoptik JENar F-Theta Scanning Lenses or Jenoptik JENar Silverline F-Theta Scanning Lenses not shown on our website. Specifications General Model Number: 739892 Type: JENar Silverline F-Theta Note: Damage Warning: Not recommended for picosecond and femtosecond laser pulses. Protective Window: #17-690 : One Included Manufacturer: Jenoptik Physical & Mechanical Properties Maximum Diameter (mm): 99.8 +0/-0.1 Weight (g): 700 X/Y Mirror Angle (°): ±7.2 Flange Distance (mm): 176.95 Input Beam Diameter, 1/e 2 (mm): 9 Maximum Length (mm): 66.5 Optical Properties Focal Length FL (mm): 103.00 Substrate: Many glass manufacturers offer the same material characteristics under different trade names. Learn More Fused Silica (Corning 7980) Scan Angle (°): ±20.1 Scan Field (mm): 50 x 50 Telecentricity (°): F-Theta Only: 2.40 With Scanner: 2.80 Working Distance (mm): 134.85 Wavelength Range (nm): 355 Damage Threshold, By Design: Damage threshold for optical components varies by substrate material and coating. Click here to learn more about this specification. 1.0 J/cm 2 * (τ/[ns]) 0.40 1.0 MW/cm 2 Scan Field Diameter (mm): 71 Focus Size Diameter, 1/e 2 (μm): 8 GDD Specification (fs 2 ): 5670 Threading & Mounting Mounting Threads: M85 x 1 Regulatory Compliance Certificate of Conformance: View ×
