1064nm CWL, 2.00 FWHM, 25mm Dia.Ultra Narrow Filter

Product Details Bandwidths Between 0.2 and 5.0nm OD 4.0 Blocking Between 200 and 1200nm Rapid Custom Designs Available Ultra Narrow Hard Coated Bandpass Filters Also Available Ultra Narrow Traditional Coated Bandpass Filters are ideal for use as laser line, laser cleanup, or laser excitation filters in demanding medical and laser applications. These filters provide OD 4 blocking by design, center wavelength tolerances as tight as 0.05nm, and bandwidths ranging from 0.2nm to 5.0nm. Multiple standard wavelength options including H-alpha hydrogen, HeNe laser, and Nd:YAG laser line are available. Rapid custom filters with bandwidth between 0.15 and 50nm and center wavelength between 340 and 2400nm are available. Please contact us for a quote. Specifications General Type: Bandpass Filter Note: Filter Design: Two-Cavity Physical & Mechanical Properties Diameter (mm): 25.00 +0.00/-0.25 Clear Aperture CA (mm): 21.00 Substrate Thickness (mm): 6 +0.00/-0.25 Optical Properties Angle of Incidence (°): 0 Center Wavelength CWL (nm): 1,064.00 Full Width-Half Max FWHM (nm): 2.00 Substrate: Many glass manufacturers offer the same material characteristics under different trade names. Learn More Soda Lime Glass & Filter Glass Minimum Transmission (%): >70 Regulatory Compliance RoHS 2015: Compliant × Certificate of Conformance: View × Reach 253: Compliant ×
