12.7mm Dia. 435nm λ/2 Quartz Waveplate

Product Details Ideal for Trapped-Ion and Neutral Atom Applications Range of Application-Specific Wavelengths from UV to NIR 12.7 and 25.4mm Diameters for Easy Integration Half Waveplates for Quantum Computing are ideal for the manipulation of polarization states in trapped ion, linear optical, and neutral atom quantum computing, as well as quantum cryptography and communication applications. These waveplates are available in a range of commonly-used, application-specific wavelengths across the UV to NIR spectrum covering the main wavelengths of commonly used ions (Ytterbium/Strontium/Calcium), and offer a retardance of λ/2 and a retardance accuracy of λ/200. Depending on wavelength, these waveplates feature either a first or zero-order construction for a low temperature-sensitivity, and are AR-coated for maximum transmission at the design wavelength to ensure optimal performance with low light signals. Half Waveplates for Quantum Computing are housed in a black, anodized aluminum mount and are available in both a 1’’ and more compact ½’’ size for easy integration into space sensitive systems. Polarizing Cube Beamsplitters for Quantum Computing are also available, and custom wavelengths are available for both. Specifications General Type: Crystalline Waveplate Configuration: Mounted, Air-Spaced Typical Applications: Trapped Ion, Yb+ Physical & Mechanical Properties Clear Aperture CA (mm): >8.00 Diameter (mm): 12.70 +0.0/-0.2 Optical Properties Design Wavelength DWL (nm): 435 Substrate: Many glass manufacturers offer the same material characteristics under different trade names. Learn More Crystalline Quartz Retardance: λ/2 Surface Quality: 20-10 Retardance Tolerance: λ/200 @ 20C Transmitted Wavefront Distortion (RMS): λ/10 @632.8nm Coating Specification: R<0.2% @ 435nm on each surface Retardance Order: Zero Coating Type: Anti-Reflection Threading & Mounting Mount Thickness (mm): 6.00 ±0.2 Mount: Anodized Aluminium Regulatory Compliance RoHS 2015: Compliant × Certificate of Conformance: View × Reach 247: Compliant ×
