300mm x 300mm, CARBONFEATHER Light Blocking Low Reflection Black Film

Product Details OD 6 Light Blocking Capability for Minimizing Stray Light Anti-Static Polyethylene Terephthalate (PET) Construction Ultra-Thin (80µm), Flexible, and Easy to Cut to Size CARBONFEATHER Light Blocking Low Reflection Black Films are ultra-black PET-based optical films designed to minimize stray light and reduce unwanted reflections in precision optical systems. These lightweight films feature excellent light absorption characteristics, low surface gloss, and anti-static performance for demanding imaging and photonic applications. Available in multiple square and circular geometries, they can be easily integrated into a wide range of prototyping and production environments. CARBONFEATHER Light Blocking Low Reflection Black Films also offer optimized surface friction properties, making them well-suited for moving optical assemblies and compact instrument designs. These films are ideal for imaging systems, camera modules, LiDAR, analytical instrumentation, low-power laser systems, apertures, shutters, and other precision optical assemblies. Note: When handling these films, it is advised to wear gloves, as finger oils can leave marks on the surface. Specifications Physical & Mechanical Properties Dimensions (mm): 300.00 x 300.00 Coefficient of Friction – Dynamic/Static: 0.22 / 0.28 Surface Roughness (μm): 1.3 Thickness (μm): 80 Optical Properties Surface Glass (60°): 2% Optical Density OD (Average): 6.0 Electrical Surface Resistivity (Ω/ Sq): 10 4 Regulatory Compliance RoHS 2015: Compliant × Certificate of Conformance: View × Reach 253: Compliant ×
