75 x 75mm, Rhodium Coated First Surface Mirror

Product Details Corrosion and Extreme Abrasion Resistant Rhodium Coating High Reflectivity in the VIS and IR Ideal for Orthodontic Applications Rhodium Coated First Surface Mirrors provide high reflectivity and are ideal for orthodontic applications, especially in intra-oral photography. These mirrors feature a rhodium coating, which is an element notably resistant to corrosion and aggressive chemicals and passes severe abrasion tests as per MIL-C-675C. Rhodium Coated First Surface Mirrors utilize a float glass substrate which enables easy customization and provides excellent cost to performance ratio. They are available in standard metric sizes, with either circular or square geometries. Specifications General Type: Flat Mirror Physical & Mechanical Properties Dimensions (mm): 75.0 x 75.0 Dimensional Tolerance (mm): ±0.25 Thickness (mm): 3.00 ±0.20 Length (mm): 75.00 Width (mm): 75.00 Edges: Seamed Bevel: Protective as needed Optical Properties Substrate: Many glass manufacturers offer the same material characteristics under different trade names. Learn More Float Glass Coating: Rhodium (400-10000nm) Coating Type: Metal Coating Specification: R avg >70% @ 400 – 700nm R avg >90% @ 2000 – 10,000nm Wavelength Range (nm): 400 – 10000 Surface Flatness (P-V): 4 – 6λ Surface Quality: 80-50 Environmental & Durability Factors Coating Abrasion: Severe, per MIL-C-675C Paragraph 3.8.4.1 Coating Adhesion: MIL-PRF-13830B, App B Para. 4.4.6 Regulatory Compliance RoHS 2015: Compliant × Certificate of Conformance: View × Reach 247: Compliant ×
