C-Mount, 35mm Sq. x 3mm Thick Plate Mount

Product Details C, S, and T-Mount Solutions for Mounting Cube and Plate Beamsplitters, Filters, and Mirrors Provides a 90° Mounting Interface ¼ -20 and M6 Tapped Mounting Threads for English or Metric Based Systems TECHSPEC C, S, and T-Mount Cube and Plate Mounts allow for the integration of cube and plate optics into C, S, and T-Mount systems. These mounts feature four C, S, or T-Mount threaded apertures that can also act as connection points for other C, S, or T-Mount components. Either an M6 or 1/4-20 tapped hole is provided on the base for post mounting, making these mounts compatible with breadboard and benchtop systems. TECHSPEC C, S, and T-Mount Cube and Plate Mounts provide a 90° mounting interface ideal for placing beamsplitters, filters, and mirrors within a system. C, S, and T-Mount Aperture Caps are available to block light from unused openings and to protect the optic from dust and debris. Note: #11-139 and #11-142 each include one S-Mount Aperture Cap ( #11-137 ) Specifications General Function: Optic Mount (Fixed) Type of Optics: Square Note: Includes one C-Mount Aperture Cap (#55-245) Dimensions of Compatible Optics (mm): 35.0 Sq. Physical & Mechanical Properties Dimensions (mm): 38.0 x 38.8 x 50.0 Extension Length (mm): 38.0 Min. Thickness of Compatible Optics (mm): 3.00 Max. Thickness of Compatible Optics (mm): 6.00 Threading & Mounting Thread Type: C-Mount Compatible Post: ¼-20 Regulatory Compliance Certificate of Conformance: View ×
