Coherent OBIS LX SF 1448284 | 405nm LX SF 40mW Single Frequency Laser

Product Details Single Frequency, Collimated, TEM 00 Output Beam Excellent Signal-to-Noise Ratio Compatible With All OBIS LX/LS Power Supplies, Software, and Accessories Coherent Single Frequency OBIS LX Laser Systems incorporate Coherent’s SureLock volume holographic grating (VHG) stabilized laser diodes to deliver consistent, single frequency performance in the same form factor as all other OBIS LX/LS platforms . Available in 405, 633, and 660nm, these laser systems excel in application spaces requiring very low RMS signal-to-noise of less than 0.05%. An excellent alternative to stabilized HeNe lasers, each laser is stabilized using Coherent’s PowerLocker volume holographic grating ensuring precise and stable center wavelengths, low temperature dependence, and consistent optical performance. Coherent Single Frequency OBIS LX Laser Systems are ideal for applications such as confocal microscopy, DNA sequencing, flow cytometry, and interferometry and are compatible with all other OBIS LX/LS power supplies, accessories, and software. OBIS Laser System Startup Guide This downloadable PDF provides guidance on interfacing with OBIS controllers and power supplies, mounting and connecting the heatsink, and starting modulation. Download Startup Guide Specifications General Warm-Up Time (minutes): <5 Manufacturer: Coherent Type of Laser: Diode Laser Class - CDRH: IIIb Model Number: 1448284 Physical & Mechanical Properties Pointing Stability (μrad/°C): <5 Pointing Stability (μrad): <30 Optical Properties Polarization: 100:1 (minimum) Spatial Mode: TEM 00 Wavelength (nm): 405.00 ±1 Mode Quality, M 2 : ≤1.5 Beam Diameter Tolerance (mm): ±0.1 Beam Diameter (mm): 0.4 Spectral Line Width (MHz): 160 Beam Divergence (mrad): Full-Angle: <2 Color: Violet Spectral Line Width (pm): 0.3 (maximum) Electrical Output Power (mW): 40 Power Stability (%): <1 RMS Noise: ≤0.05% (20Hz to 20MHz) Peak-to-Peak Noise: <0.5% (20Hz to 20kHz) Hardware & Interface Connectivity Power Supply: Power Supply Required and Sold Separately: USA: #87-473 Europe: #87-473 Japan: #87-473 Korea: #87-473 China: #87-473 Output Type: Free Space Environmental & Durability Factors Operating Temperature (°C): +10 to +50 Regulatory Compliance RoHS 2015: Exempt × Reach 224: Contains SVHC(s) × Certificate of Conformance: View ×
