High Performance Vibration Isolation System

Product Details Passive Vibration Isolation Lightweight, Compact Profile for Easy Portability Self-Leveling Design with Height Control Valves The TMC High Performance Vibration Isolation System is designed to remove the unwanted effects of vibration from challenging microscopy applications. The lightweight, low-profile design weighs only 22kg, easing portability and lab integration. The TMC High Performance Vibration Isolation System consists of an electropolished stainless steel chassis and powder finish steel top plate. The self-leveling TMC High Performance Vibration Isolation System also includes height control valves for modifying the height of the platform. Specifications General Type: Universal Physical & Mechanical Properties Thickness (inches): 3.0 Length (inches): 20.0 Width (inches): 18.0 Construction: Electropolished stainless steel sides and base Textured powder coat carbon steel top plate Feed Pressure (psi): 80 (nitrogen or air) Height (inches): 3.0 Load Capacity (kg): 67 (150 lb) Weight (kg): 22 (50 lb) Regulatory Compliance RoHS 2015: Compliant × Certificate of Conformance: View ×
