Mitutoyo FS70Z-S Microscope Head

Product Details Utilizes Mitutoyo Infinity Corrected Objectives Trinocular Design Allows for Easy Video Adaptation Turret Accepts up to Four Objectives Objectives and Light Source Sold Separately Designed to yield high magnifications at long working distances, the Mitutoyo FS70 Inspection Microscope is an ideal choice for many inspection and quality assurance applications. Incorporating Mitutoyo’s full line of visible infinity-corrected objectives , the microscope system obtains magnifications from 20X – 8000X and working distances from 6 – 34mm. The focusing eyepieces can accept 25mm diameter reticles. The 50/50 trinocular head features 50mm of coarse movement, 0.1mm/rev of fine movement, and simultaneous video and binocular viewing. Note: Objectives and illumination are sold separately. Specifications General Manufacturer: Mitutoyo Physical & Mechanical Properties Dimensions (inches): 1.75 W x 1.32 H x 3.00 D Interpupillary Distance (mm): 51 – 76 Weight (lbs): 14.5 Regulatory Compliance RoHS 2015: Exempt × Certificate of Conformance: View × REACH 241: Contains SVHC(s) ×
