Olympus SLMPLN 100X Objective

Product Details Ideal for Brightfield Microscopy Ultra-Long Working Distances Reduce Risk of Specimen Damage Over 90% Transmission from 400 – 700nm Additional Olympus Infinity Corrected Objectives Available Olympus Super Long WD M Plan Achromat Infinity Corrected Objectives are ideal for electronic assembly, semiconductor inspection, or other flat field inspection applications where resolution is critical. Olympus Super Long WD M Plan Achromat Infinity Corrected Objectives provide excellent performance, ultra-long working distances, and superior image clarity. Specifications General Model Number: SLMPLN100X Compatible Tube Lens Focal Length (mm): Focal Length: 180mm Type: Microscope Objective Style: Infinity Corrected Manufacturer: Olympus Physical & Mechanical Properties Field of View (mm): 0.26 Length excluding Threads (mm): 37.40 Maximum Diameter (mm): 26 Weight (g): 100 Optical Properties Compatible Cover Glass Thickness (mm): N/A Focal Length FL (mm): 1.80 Magnification: 100X Numerical Aperture NA: 0.60 Transmission (%): T> 90 from 400-700nm Resolving Power (μm): 0.56 Depth of Field (μm): 0.76 Working Distance (mm): 7.6 Wavelength Range (nm): 400 – 700 Field Number (mm): 26.5 Parfocal Length (mm): 45 Immersion Liquid: N/A Entrance Pupil Diameter (mm): 2.16 Threading & Mounting Mounting Threads: RMS / 20.32mm x 36 TPI Regulatory Compliance Certificate of Conformance: View ×
