Rotary Mount Table

Product Details Easily Secure Prisms or Cube Beamsplitters Adjustable for Optics up to 55mm Rotary Version Offers Manual 360° Rotation English Prism Mounts feature a steel post and anodized aluminum arm which eliminates obstructions in the optical path while still maintaining a secure position on the optic. Ideal for prisms and cube beamsplitters with a maximum height of 55mm, this prism mount features a V-cut clamp made of scratch resistant Delrin to prevent damage to optics. The Prism Holder is also available as a complete assembly with the Rotary Optic Mount , which allows smooth manual 360° rotation of the prism. English Prism Mounts have a locking knob that keep prisms securely positioned for increased repeatability. Specifications General Type: Adjustable – Rotary Type of Optics: Cube/Prism Physical & Mechanical Properties Outer Diameter (inches): 3.00 Outer Diameter (mm): 76.2 Scale Divisions: 90°-0-90° with 1° increments Construction: Black Anodized Aluminum Travel (°): 360 Threading & Mounting Size of Compatible Optics (mm): 50.0 Compatible Post: ¼-20 Regulatory Compliance Certificate of Conformance: View ×
