Sapphire 532nm, 500mW LPX CDRH Laser Head

Product Details Output Powers up to 500mW 300mW and 500mW Output Powers 488, 532, and 561nm Wavelength Options Coherent Sapphire LPX Laser Systems utilize Coherent’s unique OPSL (Optically Pumped Semiconductor Laser) technology to provide a series of CW, higher power, compact lasers. Available with 488, 532, and 561nm wavelength options, these lasers provide a high-quality diffraction limited output beam and are assembled with Coherent’s excellent pointing stability of <30 μrad. Flexible remote-control options for USB, RS-232, and analog connection all provide control options via the relevant ports on the CDRH laser controller. Coherent Sapphire LPX Laser Systems are ideal for applications that require an ultra-narrow linewidth such as Raman spectroscopy, interferometry, holography, metrology, and inspection. These lasers require #70-123 Sapphire LPX CDRH Controller for power and control, sold separately. Specifications General Warm-Up Time (minutes): <5 Manufacturer: Coherent Type of Laser: Solid State Laser Class - CDRH: IIIb Model Number: 1416018 Physical & Mechanical Properties Pointing Stability after Warm Up (mrad/°C): <5 Pointing Stability (μrad): <30 Optical Properties Spatial Mode: TEM 00 Wavelength (nm): 532.00 Mode Quality, M 2 : <1.1 Beam Diameter Tolerance (mm): ±0.05 Beam Diameter (mm): 0.70 Beam Divergence (mrad): Full Angle: <1.3 Color: Green Electrical Output Power (mW): 500 Power Stability (%): <2 RMS Noise: ≤0.25% (20Hz to 20MHz) Hardware & Interface Connectivity Power Supply: Power Supply Required and Sold Separately: USA: #70-123 Europe: #70-123 Japan: #70-123 Korea: #70-123 China: #70-123 Output Type: Free Space Environmental & Durability Factors Operating Temperature (°C): 10 to 40 Regulatory Compliance Certificate of Conformance: View ×
