SM1 Tube, 19.05mm Optic Adapter

Product Details Compatible with any SM1 Threaded Lens Tube Mounts 5mm to 19.05mm Optical Components Drop-In Mounting for Easy Assembly SM Lens Tube Drop-In Mounts allow easy integration of many standard diameter lenses into SM1 Tube Systems. Featuring a common outer diameter of 25.4mm, the mount design ensures lenses are well centered when dropped into SM1 threaded lens tubes . These drop-in mounts expand the mounting diameter capability of any SM1 threaded lens tube system from only 25.0/25.4mm diameter optics to also include 5mm, 6mm, 9mm, 10mm, 15mm, 18mm, and 19.05mm diameter optics. SM Lens Tube Drop-In Mounts are compatible with any SM1 threaded lens tube, making these mounts an essential addition to any lab or OEM system setup. Specifications General Type: Fixed Type of Optics: Circular Tube System Compatibility: SM Tube System Physical & Mechanical Properties Min. Thickness of Compatible Optics (mm): 0.50 Max. Thickness of Compatible Optics (mm): 8.50 Clear Aperture CA (mm): 18.05 Construction: Black Anodized Aluminum Threading & Mounting Size of Compatible Optics (mm): 19.05 Regulatory Compliance RoHS 2015: Compliant × Certificate of Conformance: View × REACH 241: Compliant ×
