Solid State UV Flood Light Systems

Product Details Large, Uniform UV Light Output 380nm Center Wavelength Up to 0.8W/cm 2 UV Irradiance Solid State UV Flood Light Systems produce a large, uniform output beam of UV light centered at 380nm. These systems consist of a controller box with a built-in timer for automated curing and a handheld UV flood light with an on-off switch. The controller box features integrated heat sinks and a cooling fan, allowing for continuous operation without a change in UV intensity. Solid State UV Flood Light Systems are ideal for UV curing applications, especially those with either large components or multiple small components to cure. Specifications General Operating Lifetime (hours): >20,000 Physical & Mechanical Properties Dimensions (mm): UV Curing Head: 55 x 52 x 148 Control Box: 160 x 150 x 80 Optical Properties Wavelength (nm): 380.00 ±5 Working Distance (mm): 30 – 100 Beam Size (mm): 50 x 50mm (30mm WD) 100 x 100mm (100mm WD) Irradiance (W/cm 2 ): 0.8 Electrical Power Requirement: AC 100 – 240V Regulatory Compliance Certificate of Conformance: View ×
